Compact, Cost-Effective 6.5 GHz VNA Delivering High Performance for R&D and Production

---

Siglent Technologies officially announces the release of the SNA5000X-E Vector Network Analyzer, a compact and cost-effective solution designed to meet essential RF testing requirements without compromising performance. Covering a frequency range from 9 kHz to 6.5 GHz and delivering a typical dynamic range of 125 dB, the SNA5000X-E provides accurate, reliable measurements for R&D, education, and production environments.

Positioned as an entry-level model within the SNA5000 series, the SNA5000X-E retains the core performance architecture of the SNA5000A family while offering enhanced cost-effectiveness for standard vector network analysis applications. It supports 1 Hz frequency resolution, adjustable IF bandwidth from 1 Hz to 10 MHz, and an output power range from –40 dBm to +10 dBm. With its 125 dB typical dynamic range, the instrument maintains excellent measurement stability and accuracy even in complex RF test scenarios.

---

The SNA5000X-E supports comprehensive S-parameter and differential measurements, along with integrated time-domain analysis, enhanced time-domain analysis, and spectrum analysis functions. These capabilities enable engineers to evaluate frequency-domain characteristics, analyze impedance discontinuities, and quickly locate faults within devices under test. A built-in eye diagram function further supports high-speed signal integrity analysis, improving debugging efficiency during development.

To address fixture-induced measurement errors commonly encountered in RF testing, the SNA5000X-E incorporates automatic fixture removal, port extension, de-embedding, and impedance conversion functions. These tools effectively compensate for cable delay and loss, minimizing systematic errors and ensuring high confidence in measurement results.

Designed for modern laboratories and production lines, the SNA5000X-E features a compact form factor with an instrument depth of only 12.6 cm and a weight of less than 5.4 kg. This significantly reduces workspace requirements compared to traditional network analyzers. The instrument is equipped with a 12.1-inch touchscreen that supports multi-window display and multiple data formats, creating an intuitive and efficient operating experience.

For production and automated test environments, the SNA5000X-E offers one-click filter characteristic analysis to quickly obtain key parameters such as insertion loss and bandwidth. It also supports custom formula operations and remote control via SCPI and WebServer, enabling seamless integration into automated systems and helping standardize and streamline testing workflows.

By returning to the fundamentals of vector network analysis, the SNA5000X-E combines essential performance, intelligent operation, and compact design in an economical solution. It provides a reliable, one-stop platform for applications ranging from R&D validation to batch quality inspection, enabling engineers to achieve professional RF measurement capability with optimized investment.

Upgrade to Top Spec for Free, Save Up to $2,600!

Unlock the full potential of your testing capabilities with our latest promotion on the SSG3000X Series signal generators.

For a limited time, when you purchase the SSG3032X, we’ll upgrade your unit free of charge to the top-of-the-line SSG3032X-IQE — the highest specification model in the series.

That means you’re not just getting a great deal — you’re getting up to $2,600 in added value, with full access to:

Maximum performance at no extra cost

I/Q modulation feature

Model	Frequency Range	I/Q Modulation	Price
SSG3032X	9 kHz~3.2 GHz	NO	$4,090
Free upgrade to:
SSG3032X-IQE	9 kHz~3.2 GHz	YES	$6,690

Notes:

• Offer valid until July 31, 2026, while supplies last.
• Cannot be combined with other discounts or promotions
• This promotion is only available in North America.

To find out more about this great offer, contact quote@siglentna.com.

The new Arbitrary Waveform Generator Combines RF Signal Generation, IQ Modulation and Advanced Sequencing in a Single Platform

SIGLENT Technologies announced the launch of the new SDG8000A Series Arbitrary Waveform Generators, a high-performance signal generation platform designed for advanced RF, wireless communication, semiconductor and high-speed digital applications.

As modern communication and RF systems continue to increase in complexity, developers require signal sources capable of generating wideband, highly dynamic and realistic signals with exceptional fidelity. The SDG8000A Series was developed to address these requirements by combining wideband arbitrary waveform generation, direct RF signal synthesis, IQ vector signal generation and advanced sequencing capabilities in a single instrument platform.

The SDG8000A Series delivers in IQ-Mode output frequencies up to 5 GHz with sampling rates up to 12 GSa/s (interpolation) and 16-bit vertical resolution. Available in two- and four-channel configurations, the new platform provides up to 4 Gpts waveform memory per channel, enabling the generation of long and highly complex signal scenarios for modern RF and communication development.

Using SIGLENT’s TrueArb technology, arbitrary waveforms can be reproduced point-by-point while maintaining waveform detail and low jitter performance. The architecture supports narrow pulse generation down to 250 ps and provides advanced multi-pulse functionality for demanding applications in RF, semiconductor and power electronics development.

A key capability of the SDG8000A Series is its integrated RF and IQ signal generation architecture. The internal digital modulator enables direct RF output up to 5 GHz without requiring external IQ modulation hardware. Combined with the optional SigIQPro software package, the system supports signal generation for modern communication standards including 5G NR, LTE, Wi-Fi, Bluetooth and IoT applications. With modulation bandwidths up to 2 GHz, the platform is well suited for RF front-end validation, receiver testing, amplifier characterization and wireless communication development.

The new series also integrates advanced signal creation capabilities such as multi-tone, chirp and PRBS signal generation, as well as high-speed serial data output up to 1.25 Gbps. Its multi-level sequence architecture enables the creation of highly dynamic and realistic signal environments for burst communication, interference simulation and system-level testing applications.

For synchronized multi-channel systems, the SDG8000A Series provides inter-channel skew below 15 ps together with differential output modes, marker outputs, external clock synchronization and advanced triggering capabilities. These features make the platform suitable for MIMO and other synchronized RF test environments.

The SDG8000A Series further supports LAN connectivity, WebServer-based remote control and integrated SSD storage, enabling efficient integration into automated test systems and modern laboratory environments.

About Siglent:

SIGLENT TECHNOLOGIES began in 2002 with the development of its first digital oscilloscopes. Since then, the company has rapidly expanded its portfolio to cover a broad range of general-purpose electronic test and measurement instruments, including oscilloscopes, signal and function/arbitrary waveform generators, digital multimeters, laboratory power supplies, electronic DC loads, spectrum analyzers, vector network analyzers (VNAs), and RF signal generators.

With the introduction of the Performance Line Series in 2021, SIGLENT further advanced its technical capabilities to address demanding applications in high-performance measurement environments, including solutions reaching into the microwave frequency range up to 40 GHz.

Today, SIGLENT TECHNOLOGIES is a globally recognized provider of electronic test and measurement equipment, combining innovative features, strong engineering expertise, and reliable performance. Headquartered in Shenzhen, China, with international subsidiaries in the United States, Germany, Japan, and Malaysia, SIGLENT supports customers in more than 80 countries worldwide.

SIGLENT is certified according to ISO 9001:2015 and ISO 14001:2015 standards, reflecting its commitment to consistent product quality and responsible environmental management.
